S-Type Hydraulic Jack

Capacity : 240- 1350 ton | Stroke : 150mm Features: High-strength forged cylinders, enhancing overall reliability. Precision engineering for top performance Max. working pressure as high as 30MPa| 4351psi, max.stroke 150mm|5.91in. Specifications: Capacity Stroke (mm) Max. Pressure at Max. Load Diameter of Single Jack (mm) 240T 150 30MPa 370 320T 150 30MPa 420 430T 150 30MPa 470 530T 150 30MPa 520 630T 150 30MPa 570 730T 150 30MPa 620 870T 150 30MPa 670 1000T 150 30MPa 720 1200T 150 30MPa 770 1350T 150 30MPa 820 Note: (1) Ready stock for the S-type hydrau...
